AFR250 AFRP250电线

适用范围：适用于航空航天、电器、电讯设备和仪器仪表线路。

使用温度：-60℃～+250℃

结构图（如图）

   1——镀银、镀锡铜线或裸铜线

   2——聚四氟乙烯薄膜绝缘（PTFE）

   3——镀银或镀锡铜线编织

技术性能

   额定电压：150V、300V、600V

   试验电压：1000V、1500V、2500V

结构数据（如表）

导电线芯电线最大外径mm截面

mm2根数线径

mm标称直径mmAFR型AFRP型110V250V600V110V250V600V0.0137×0.050.150.380.490.710.700.821.020.0357×0.080.240.470.580.810.850.911.140.067×0.100.300.550.650.870.900.971.200.087×0.12

19×0.070.360.600.700.931.001.031.260.107×0.14

19×0.080.420.700.831.001.051.151.300.147×0.16

19×0.100.500.730.851.051.051.181.450.207×0.20

19×0.120.600.850.971.301.301.401.700.357×0.25

19×0.160.80 1.201.50 1.601.900.507×0.30

19×0.180.90 1.301.60 1.702.000.807×0.37

19×0.231.10 1.651.85 2.052.301.0019×0.261.30 1.882.00 2.252.451.2019×0.281.40 1.952.15 2.382.551.5019×0.321.60 2.152.35 2.632.832.0019×0.371.85 2.402.60 2.973.082.5019×0.14

49×0.262.34  2.95 3.203.433.0049×0.282.52  3.10 3.373.504.0049×0.322.88  3.52  4.12
